Typical Properties and Field Applications
SGA technology was commercialized in 2016 successfully and has been applied in various oil and gas fields in the world. It has been proved to be effective in treatment of carbonate reservoirs with the following conditions:
|
Temperature: |
BHST 60‑300°F (15‑149°C) |
|
Formation: |
Carbonates with variation in petro‑physical properties |
|
Treatment fluids: |
HCl, self‑diverting acids |
|
Mix‑water: |
Fresh water |
Precautions and HSE Considerations
Acid gelling agent (KMA027G), SGA crosslinker (KMA024) and SGA iron control agent (KMA022B) in SGA systems play the most important roles in fluid and treatment design. In addition, corrosion inhibitor (KMA034C) and inhibitor aid (KMA030 and KMA031) are generally used in SGA systems to protect the tubing from corrosion. H2S scavenger (KMA009) and H2S scavenger Aid (KMA009B) are compatible with other system additives if they are required in SGA design.
The laboratory procedures, quality assurance program and guidelines for field mixing and handling of SGA systems are described in SGA fluid manual.
Refer to the technical sheet and SDS of the respective product for the health, safety and environmental information of each product.
